Data Viz animation and interactivity in Quarto

Deepsha Menghani

2023-09-20

My goal is to answer

- What is Data Viz animation, interactivity and linking?

- How can you get started with it in your storytelling?

- What is Data Viz animation, interactivity and linking?

- And have fun learning!!

- How can you get started with it in your storytelling?

- What is Data Viz animation, interactivity and linking?

There are lots of amazing packages for animation and interactivity like…

Shiny

Highcharter

Plotly

Crosstalk

Observablejs Plot

Ggiraph

Gganimate

And many more…

For this presentation, I will share examples of -

Plotly

Crosstalk

But first.. What is Ted Lasso and who is Roy Kent?

Ted Lasso left and Roy Kent on the right

Various moods of Roy Kent

Agitated Roy Kent saying what the f-ck

Mad

Agitated Roy Kent saying what the f-ck

Sad

Agitated Roy Kent saying what the f-ck

Happy

Agitated Roy Kent saying what the f-ck

Amused

Agitated Roy Kent saying what the f-ck

Loving

Agitated Roy Kent saying what the f-ck

Surprised

Agitated Roy Kent saying what the f-ck

Thoughtful

Agitated Roy Kent saying what the f-ck

Joyous

So, let’s look at the number of F-bombs dropped by Roy Kent!

How do I know this?

Because I watched each episode at 2X speed and diligently noted down every F*bomb and gesture reference!!

FOR SCIENCE!!

Animation

Q1: What season did Roy Kent end up dropping the most number of F-bombs?

By adding animation you can

Hold the tension in your story
Add a third variable to your plot not directly visible in a static 2D plot

Code structure for creating animation using Plotly

Simple bar plot


dataset |>
  plotly::plot_ly(y=~count, x = ~season) |>
  add_bars(type="bar")

Bar plot with animation


dataset |>
  plotly::plot_ly(y=~count, x = ~season) |>
  add_bars(frame = ~Episode, type="bar")

Code structure for creating animation using Plotly

Simple bar plot


dataset |>
  plotly::plot_ly(y=~count, x = ~season) |>
  add_bars(type="bar")

Bar plot with animation


dataset |>
  plotly::plot_ly(y=~count, x = ~season) |>
  add_bars(frame = ~Episode, type="bar") |>
  animation_opts(frame = 800, transition = 300)

Interactivity

Let’s get technical and talk about statistics

Let’s get technical and talk about statistics - “F-SCORE”

What is an episode’s F-SCORE

\[ f-score = {Roy Kent F-bombs / \choose Total F-bombs} * 100 (\%) \]

Q2: Which season has the most number of episodes with Roy Kent’s F-Score > 50%?

Can you guess the answer?

Season 1 - Total F-bombs: 56
Season 2 - Total F-bombs: 106
Season 3 - Total F-bombs: 138

We can display F-score for each episode as below

Or we can add a “season” checkbox

Season

Through interactivity you can

Turn your viz to a dashboard style report
Make your viz more accessible

Code structure for adding interativity with Crosstalk

Simple bar plot

dataset |>
  plotly::plot_ly(y=~F_score, x = ~episode) |>
  add_bars(type="bar")

Code structure for adding interativity with Crosstalk

Bar plot with interativity

shared_data <- crosstalk::SharedData$new(dataset)

Code structure for adding interativity with Crosstalk

Bar plot with interativity

shared_data <- crosstalk::SharedData$new(dataset)

plot <- shared_data |>
  plotly::plot_ly(y=~F_score, x = ~episode) |>
  add_bars(type="bar")

Code structure for adding interativity with Crosstalk

Bar plot with interativity

shared_data <- crosstalk::SharedData$new(dataset)

plot <- shared_data |>
  plotly::plot_ly(y=~F_score, x = ~episode) |>
  add_bars(type="bar")

checkbox_season <- crosstalk::filter_checkbox(
        id = "Season",
        label = "Season",
        sharedData = shared_data,
        group = ~Season
)

Code structure for adding interativity with Crosstalk

Bar plot with interativity

shared_data <- crosstalk::SharedData$new(dataset)

plot <- shared_data |>
  plotly::plot_ly(y=~F_score, x = ~episode) |>
  add_bars(type="bar")

checkbox_season <- crosstalk::filter_checkbox(
        id = "Season",
        label = "Season",
        sharedData = shared_data,
        group = ~Season
)

bscols(checkbox_season, plot)

Linking

Q3: Did Roy Kent have a lower average F-score while dating Keeley or while he was coaching?

We can use a bar plot to display average F-Score

This is just fine… but as Roy Kent said -

Roy Kent saying - Don't you dare settle for fine

So, let’s enable additional insights by linking it to another plot

Through linking you can

Add layers to your story
Give your stakeholders more control to explore and arrive at their own insights

Code structure for linking two plots

shared_data <- crosstalk::SharedData$new(dataset, key=~Dating_Coaching_flag)

Code structure for linking two plots

shared_data <- crosstalk::SharedData$new(dataset, key=~Dating_Coaching_flag)

plot1 <- shared_data |>
  plotly::plot_ly() |>
  group_by(Dating_Coaching_flag) |>
  summarise(avg.fscore = mean(F_score, na.rm=TRUE)) |>
  add_bars(y = ~Dating_Coaching_flag, x = ~avg.fscore, type="bar")

Code structure for linking two plots

shared_data <- crosstalk::SharedData$new(dataset, key=~Dating_Coaching_flag)

plot1 <- shared_data |>
  plotly::plot_ly() |>
  group_by(Dating_Coaching_flag) |>
  summarise(avg.fscore = mean(F_score, na.rm=TRUE)) |>
  add_bars(y = ~Dating_Coaching_flag, x = ~avg.fscore, type="bar")

plot2 <- shared_data |>
  plotly::plot_ly(x = ~Episode, y = ~F_count) |>
  add_bars(type="bar")

Code structure for linking two plots

shared_data <- crosstalk::SharedData$new(dataset, key=~Dating_Coaching_flag)

plot1 <- shared_data |>
  plotly::plot_ly() |>
  group_by(Dating_Coaching_flag) |>
  summarise(avg.fscore = mean(F_score, na.rm=TRUE)) |>
  add_bars(y = ~Dating_Coaching_flag, x = ~avg.fscore, type="bar")

plot2 <- shared_data |>
  plotly::plot_ly(x = ~Episode, y = ~F_count) |>
  add_bars(type="bar")

subplot(plot1,plot2)

Code structure for linking two plots

shared_data <- crosstalk::SharedData$new(dataset, key=~Dating_Coaching_flag)

plot1 <- shared_data |>
  plotly::plot_ly() |>
  group_by(Dating_Coaching_flag) |>
  summarise(avg.fscore = mean(F_score, na.rm=TRUE)) |>
  add_bars(y = ~Dating_Coaching_flag, x = ~avg.fscore, type="bar")

plot2 <- shared_data |>
  plotly::plot_ly(x = ~Episode, y = ~F_count) |>
  add_bars(type="bar")

subplot(plot1,plot2) |>
  plotly::highlight(
              persistent = TRUE
            , on = "plotly_click"
            , off = "plotly_doubleclick"
            , dynamic = TRUE)
